> 60 years of the synth

All analogue and chipsMonoPoly was an ingenious

As the 80s dawned, the scene was set for a decade where synth technology would become available to all, and synthpop would rule the charts. But then things got very digital

> After the incredible leaps in synthesiser technology that were made in the late 70s, 1980 could be regarded as the year that was the calm before the beautiful storm.

There weren’t many influential product releases in this year, the most notable being the Sequential Prophet-10. This instrument has an interesting history, as the original goal was to create a 10-note polyphonic Prophet.

The problem was that there were various issues, particularly with the synth overheating, so the solution was to create another behemoth of a synthesiser, which was essentially two Prophet-5s stacked on top of each other! There was a little more to it than that, largely centred around additional controls, but it was pricey and early models had technical issues. This meant that it did not sell in vast numbers, making it a particularly collectible synthesiser.

The Prophet-10 did not represent anything new, which is certainly not the case when it comes to the following year, when a positive avalanche of now classic products hit the market. In 1981 we have to begin with Roland, who could be regarded as the most dominant synth force throughout the 80s, and it certainly doesn’t get much more dominant than the Jupiter-8. An 8-note polyphonic synthesiser, with a split and layer function, and two oscillators per voice, it was also under microprocessor control, meaning that it offered a full 64 patch memory locations, with the additional ability to dump the patches to a data cassette. It could sound huge, by placing it in unison mode, which would allow the stacking of 16 oscillators on a single note, or it could sound brassy and beautiful, with synthetic string sounds and pads that have since become a part of the production psyche. It was also reliable, well made, and despite its relative complexity, pretty easy to use, thanks to a very obvious signal path which was laid out on a stunning metal panel. It also employed an on-board arpeggiator, which could be synchronised to a Clock pulse. The Jupiter underwent a revision, a couple of years later, to become the model often described as the Jupiter-8A. Apart from some subtle changes under the hood, it’s all about the introduction of the Roland proprietary format called DCB (Digital Communication Buss). This allowed extensive communication with a number of other Roland products, for the purposes of sequencing and synchronising across units, such as drum machines.

Still Japan vs America

Korg also grabbed the momentum in 1981, producing two incredibly interesting machines; the MonoPoly was an ingenious synthesiser, that allowed the use of four voltagecontrolled oscillators, which could be stacked to create a huge monosynth sound, or split to use polyphonically, in much the same way that Oberheim had made use of their individual SEMs in the 4-voice. Where polyphonic synthesisers were aimed at the musical mainstream, the MonoPoly offered capacity for all sorts of experimentation. However, if you only wanted a more modest polysynth, help was also at hand from Korg, in the shape of their Polysix. Originally priced at just over £1000, the Polysix provided some exceptionally good oscillators, albeit limited to one per voice. No surprise that it became a big hit with many keyboard players in bands, as it was deemed to be an affordable polysynth option.

Meanwhile Stateside, Sequential released what would become another one of their esteemed classics; the Pro One could be rather unkindly considered to be a single voice from a Prophet-5. It lost the wooden case in favour of much cheaper rigid plastic, but what really set it apart was its extraordinary sound, emanating from two oscillators, white noise, and an exceptional-sounding filter, with some of the snappiest envelopes you could find. Hence, it was a huge hit for fast basses and percussive sounds. It also featured a very creative modulation section, allowing for numerous routings between sections on the synth. It was favourably affordable (if compared to a Minimoog that is).

“This was a synthesiser development, and the time was ripe for something new”

Moog had also been tinkering around with various other synthesisers, but a notable machine also appeared in 1981 in the shape of the Moog Source. While the Source did not match the Minimoog sonically, or aesthetically for that matter, in an attempt to move the technology forward and bring the price of the product down, the Source introduced the feature of digital parameter access. What this means from the user’s perspective is that you’d select a parameter, and then use an encoder dial to apply the amount to that parameter. There is no doubt that as a consequence, the Source looked far less like a synthesiser than its counterparts, but it set a precedent for future machines, which is still very firmly a principle which is in play today.

All new synthesis

Pretty much all of the synthesisers that appeared in the commercial marketplace, up until this point, relied heavily on the principle of subtractive synthesis, set out in the 60s. This was an age of synthesiser development, and the time was ripe for something new.

Wolfgang Palm started his own company called Palm Products GmbH, in the late 70s. He spent much of his time working on a new form of synthesis, which involved the use of time of microprocessors, with an audio output fed through conventional analogue filters and amplifiers. After some relatively unsuccessful attempts in the late 70s, 1981 saw the release of his first major synthesiser, the PPG Wave 2. The principle of wavetable synthesis involves the use of a complex waveform, known as a wavetable. This replaces the conventional oscillator wave form, in subtractive terms, and allows for movement across the wave, to create evolving textures, the like of which had not been heard before, at least in the mainstream. This initial release was a large 8-voice synthesiser, with two further revisions increasing the voice count to 16. It was quite an extraordinary concept, and one that could be considered to be ahead of its time. It was popular with numerous artists, including the one and only Thomas Dolby, who was a selfproclaimed PPG fan. It also offered connectivity to its larger computer-based brother, the Wave Term. This allowed easier editing through a larger display, as well as the ability to save wavetables to disk.
